Product Show
|
|
|
|
|
Detail Info |
| Camera |
| Image Sensor: |
1/3” DIS |
| Signal System: |
PAL/NTSC |
| Effective Pixels: |
720(H)×480(V) |
| Min. Illumination: |
0.1 lux @ (F1.2, AGC on), 0 lux with IR
0.2 lux @ (F1.8, AGC on), 0 lux with IR |
| Shutter Time: |
1/25(1/30) s to 1/15,000 s |
| Lens: |
3.6 mm @ F1.8 (3.6 mm, 6 mm optional) Angle of view: 70.6° (3.6 mm) |
| Lens Mount: |
M12 |
| Adjustment Range: |
Pan: 0 - 360°, Tilt: 0 -90°, Rotation: 0 - 360° |
| Day& Night: |
IR cut filter with auto switch |
| Horizontal Resolution: |
600TVL |
| Synchronization: |
Internal Synchronization |
| Video Output: |
1Vp-p Composite Output (75Ω/BNC) |
| S/N Ratio: |
More than 52dB | |
| General |
| Operating Conditions: |
-40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)
|
| Power Supply: |
12 V DC±10% |
| Power Consumption: |
Max. 2 W
(Max. 5 W with IR cut filter on) |
| Weather Proof: |
IP66 |
| IR Range: |
Approx 10 to 20 meters |
| Dimension: |
Φ70×154.3 mm ( Φ2.76” ×6.07”) |
| Weight: |
450 g (0.99 lbs) | |
|
|
|
